Lapp 00100224 ÖLFLEX CLASSIC 100 Control Cable 3G0.75 300/500V

The Lapp 00100224 is an ÖLFLEX CLASSIC 100 flexible control cable with 3 cores of 0.75mm² (3G0.75), including a green/yellow PE conductor, rated 300/500V. Unshielded with numbered cores + 1 green/yellow PE, transparent PVC outer sheath, oil-resistant. Sold per metre, cut from reel.

Technical specifications:

• Part number: 00100224
• Manufacturer: Lapp
• Series: ÖLFLEX CLASSIC 100
• Core configuration: 3G0.75
• Conductor cross-section: 0.75mm² per core
• Rated voltage: 300/500V
• Conductor: Fine-stranded copper, Class 5 to IEC 60228
• Shielding: Unshielded
• Core identification: numbered cores + 1 green/yellow PE
• Outer sheath: PVC, transparent, oil-resistant
• Temperature range: -15°C to +70°C (moving), -40°C to +80°C (fixed)
• Flame retardancy: IEC 60332-1-2
• Sold: Per metre (cut to length)

Applications:

• Control cabinet wiring in machine tools and industrial machinery
• Connecting sensors, actuators and control devices to PLCs
• Internal wiring of distribution boards and switchgear
• General flexible control wiring in industrial environments

Compliant with IEC 60228, IEC 60332-1-2. RoHS compliant.

Also known as: Lapp 00100224, ÖLFLEX CLASSIC 100 3G0.75, Lapp control cable 3 core 0.75mm², flexible control cable 3G0.75, Lapp OLFLEX 100 3G0.75.
