Legrand 412253 T1+T2 12.5kA 2-pole Surge Arrester

The Legrand 412253 is part of the Surge Protection Devices (SPD) range. T1+T2 12.5kA 2-pole Surge Arrester.

Technical specifications:

• Catalog reference: 412253
• Manufacturer: Legrand
• EAN: 3414970518248
• product type: Combined Type 1+2 Surge Protective Device (SPD)
• type: T1+T2
• poles: 2P
• iimp: 12.5 kA
• nominal discharge current: 20 kA (8/20)
• Nominal voltage: 400 V AC
• max continuous voltage uc: 320 V AC
• voltage protection level up: 1.7 kV
• Mounting: DIN rail 35 mm
• Width (modules): 4
• conductor cross section solid: 35 mm²
• conductor cross section flexible: 25 mm²
• signalling: Optical
• Degree of protection (IP): IP20
• Standards: EN/IEC 61643-11
• compatible systems: TN, TN-C, TN-C-S, TN-S
• manufacturer: LEGRAND

Features and benefits:

• Manufactured by Legrand for professional electrical installations.

Applications:

• Professional electrical installations using the Surge Protection Devices (SPD) range.

Also known as: Legrand 412253, 412253, Surge Protection Devices (SPD).
