Schneider A9D20610 Acti9 DPN Vigi K RCBO 1P+N C 10A 6kA 30mA

The Schneider Electric Acti 9 DPN Vigi K (A9D20610) is a 1P+N residual current breaker with overcurrent protection (RCBO) from the Acti 9 range, combining earth-fault and overcurrent protection in a single device for final circuit protection in residential and commercial installations.

• Reference: A9D20610
• Model: Acti 9 DPN Vigi K
• Type: RCBO (residual current breaker with overcurrent protection)
• Poles: 1P+N
• Rated current (In): 10 A
• Tripping curve: C
• Breaking capacity (Icn): 6000 A at 220–240 V AC 50 Hz
• RCD sensitivity (IΔn): 30 mA, type AC
• Rated voltage (Ue): 220–240 V AC 50 Hz
• Standard: EN/IEC 61009-2-1
