Schneider A9D22616 Acti9 DPN Vigi K RCBO 1P+N B 16A 6kA 30mA

The Schneider Electric A9D22616 is a 1P+N RCBO (residual current circuit breaker with overcurrent protection) from the Acti 9 DPN Vigi K range, providing combined overload, short-circuit, and earth-fault protection on single-phase circuits in residential and commercial installations.

• Reference: A9D22616
• Range: Acti 9
• Model: DPN Vigi K
• Type: RCBO (residual current circuit breaker with overcurrent protection)
• Poles: 1P+N
• Rated current (In): 16 A
• Tripping curve: B
• Breaking capacity (Icn): 6000 A at 220...240 V AC 50 Hz
• RCD sensitivity (IΔn): 30 mA
• RCD type: AC
• Rated voltage (Ue): 220...240 V AC 50 Hz
• Standard: EN/IEC 61009-2-1
