Schneider A9D22620 Acti9 DPN Vigi K RCBO 1P+N B 20A 6kA 30mA

The Schneider Electric Acti9 DPN Vigi K (A9D22620) is a 1P+N RCBO that combines overcurrent protection and residual-current protection in a single module, for use in final circuits of single-phase 220–240 V AC domestic and light commercial installations.

• Reference: A9D22620
• Range: Acti 9
• Model: DPN Vigi K
• Type: RCBO (Residual Current Circuit Breaker with Overcurrent protection)
• Poles: 1P+N
• Rated current (In): 20 A
• Tripping curve: B
• Breaking capacity (Icn): 6000 A at 220...240 V AC 50 Hz
• RCD sensitivity (IΔn): 30 mA
• RCD type: AC
• Rated voltage (Ue): 220...240 V AC 50 Hz
• Standard: EN/IEC 61009-2-1
