Schneider C104TM100 TM100D ComPacT NSX Trip Unit 4P 100A 690V

The C104TM100 is a TM100D thermomagnetic trip unit for Schneider Electric ComPacT NSX100, NSX160, and NSX250 moulded-case circuit breakers. It provides 4-pole, 4-wire protection with a fully protected neutral, for systems rated up to 690 V AC 50/60 Hz.

• Reference: C104TM100
• Range: ComPacT NSX100/160/250
• Model: TM100D
• Type: Thermomagnetic trip unit
• Poles: 4P 4D (neutral fully protected)
• Rated current (In): 100 A
• Rated voltage (Ue): 690 V AC 50/60 Hz
