Schneider C106TM100 ComPacT NSX TM100D Trip Unit 4P 100A 690V

The Schneider Electric C106TM100 is the TM100D thermomagnetic trip unit designed for use with ComPacT NSX100, NSX160, and NSX250 moulded-case circuit breakers. It provides overcurrent and short-circuit protection in 4-pole installations where the neutral conductor is not protected.

• Reference: C106TM100
• Range: ComPacT NSX100/160/250
• Model: TM100D
• Product type: Thermomagnetic trip unit
• Poles: 4P 3D (neutral not protected)
• Rated current (In): 100 A
• Rated voltage (Ue): 690 V AC 50/60 Hz
