Schneider C10H3 ComPacT NSX100H MCCB Base Frame 3P 100A 70kA Without Trip Unit

The Schneider Electric C10H3 is a 3-pole base frame (bare chassis) for the ComPacT NSX100H moulded-case circuit breaker range, supplied without a trip unit. Intended for industrial power distribution, it provides the mechanical housing ready to accept a compatible protective trip unit.

• Reference: C10H3
• Range: ComPacT NSX (new generation)
• Model: NSX100H
• Type: Base frame, without trip unit
• Poles: 3P
• Rated current (In): 100 A at 40 °C
• Rated voltage (Ue): 690 V AC 50/60 Hz per IEC 60947-2
• Breaking capacity (Icu): 70 kA at 415 V AC
• Utilisation category: Category A
