Schneider C10N3 ComPacT NSX100N MCCB 3P 100A 50kA Basic Frame

The Schneider Electric C10N3 is a basic frame moulded-case circuit breaker (MCCB) from the ComPacT NSX new generation range, model NSX100N, supplied without a protection unit and designed to accept a separately sourced trip unit for flexible protection configuration.

• Reference: C10N3
• Range: ComPacT NSX new generation
• Model: NSX100N
• Type: Basic frame (without protection unit)
• Poles: 3P
• Rated current (In): 100 A at 40°C
• Breaking capacity (Icu): 50 kA at 415 V AC
• Rated voltage (Ue): 690 V AC 50/60 Hz, IEC 60947-2
• Utilisation category: Category A
