Schneider C16F3 ComPacT NSX160F Basic Frame 3P 160A 36kA 690V AC

The Schneider Electric C16F3 is a 3-pole basic frame (without trip unit) from the ComPacT NSX new generation range, model NSX160F. Rated at 160 A at 40 °C and 690 V AC, it accepts a separately ordered trip unit for use in industrial power distribution and motor circuit protection installations.

• Reference: C16F3
• Range: ComPacT NSX new generation
• Model: NSX160F
• Type: Basic frame (without trip unit)
• Poles: 3P
• Rated current (In): 160 A at 40 °C
• Rated voltage (Ue): 690 V AC, 50/60 Hz, IEC 60947-2
• Breaking capacity (Icu): 36 kA at 415 V AC
• Utilisation category: Category A
