Schneider C16F4 ComPacT NSX160F MCCB Basic Frame 4P 160A 36kA 690V AC

The Schneider Electric C16F4 is a 4-pole moulded-case circuit breaker (MCCB) basic frame from the ComPacT NSX new generation range, designed to accept a separately fitted trip unit for flexible protection configuration in industrial power distribution systems.

• Reference: C16F4
• Range: ComPacT NSX new generation
• Model: NSX160F
• Type: Basic frame (without trip unit)
• Poles: 4P
• Rated current (In): 160 A at 40°C
• Breaking capacity (Icu): 36 kA at 415 V AC
• Rated voltage (Ue): 690 V AC 50/60 Hz
• Standard: IEC 60947-2
• Utilisation category: Category A
