Schneider C16H3 ComPacT NSX160H MCCB Base Frame 3P 160A 70kA

The Schneider Electric C16H3 is a ComPacT NSX160H new-generation moulded-case circuit breaker (MCCB) base frame, supplied without a trip unit. Intended for industrial power distribution up to 690 V AC, it accepts a separately ordered trip unit to complete the assembly.

• Reference: C16H3
• Range: ComPacT NSX new generation
• Model: NSX160H
• Type: Base frame (without trip unit)
• Poles: 3P
• Rated current (In): 160 A at 40°C
• Rated voltage (Ue): 690 V AC 50/60 Hz
• Breaking capacity (Icu): 70 kA at 415 V AC
• Utilisation category: Category A
• Standard: IEC 60947-2
