Anbieter: SCHNEIDER ELECTRIC
Schneider C25F3 ComPacT NSX250F Base Frame 3P 250A 36kA MCCB
Beschreibung
The C25F3 is the bare-frame enclosure for the ComPacT NSX250F moulded-case circuit breaker (MCCB), part of the Schneider Electric ComPacT NSX new generation range. It is supplied without a trip unit, accepting separately ordered trip units and accessories for flexible protection configuration in industrial power distribution.
- Reference: C25F3
- Range: ComPacT NSX new generation
- Model: NSX250F
- Product type: Base frame (without trip unit)
- Poles: 3P
- Rated current (In): 250 A at 40°C
- Breaking capacity (Icu): 36 kA at 415 V AC
- Rated voltage (Ue): 690 V AC, 50/60 Hz
- Standard: IEC 60947-2
- Utilisation category: Category A
