Schneider C25F44V250 NSX250F MCCB 4P 250A 36kA MicroLogic Vigi 4.2

The Schneider Electric C25F44V250 is a 4-pole ComPacT NSX250F moulded-case circuit breaker (MCCB) from the ComPacT NSX new generation range, equipped with a MicroLogic Vigi 4.2 protection unit for integrated earth leakage protection. Suited for industrial power distribution where both overcurrent and residual current protection are required.

• Reference: C25F44V250
• Range: ComPacT NSX new generation
• Model: NSX250F
• Poles: 4P
• Rated current (In): 250 A at 40 °C
• Breaking capacity (Icu): 36 kA at 415 V AC
• Trip unit: MicroLogic Vigi 4.2
• RCD class: Class A
• Rated voltage (Ue): 440 V AC 50/60 Hz
• Utilisation category: Category A
