Schneider C25H3 ComPacT NSX250H MCCB 3P 250A 70kA Basic Frame

The Schneider Electric C25H3 is a 3-pole basic frame from the ComPacT NSX new generation range, model NSX250H. It is a moulded-case circuit breaker chassis supplied without a trip unit, suited for industrial power distribution and protection applications.

• Reference: C25H3
• Range: ComPacT NSX new generation
• Model: NSX250H
• Type: Basic frame (chassis without trip unit)
• Poles: 3P
• Rated current (In): 250 A at 40°C
• Breaking capacity (Icu): 70 kA at 415 V AC
• Rated voltage (Ue): 690 V AC 50/60 Hz per IEC 60947-2
• Utilisation category: Category A
