Schneider C40F3 ComPacT NSX400F MCCB Basic Frame 3P 400A 36kA

The Schneider Electric C40F3 is a 3-pole basic frame without trip unit from the ComPacT NSX new generation range, model NSX400F. It is a moulded-case circuit breaker chassis for industrial power distribution assemblies requiring a separately fitted protective unit.

• Reference: C40F3
• Range: ComPacT NSX new generation
• Model: NSX400F
• Type: Basic frame (without trip unit)
• Poles: 3P
• Rated current (In): 400 A at 40 °C
• Breaking capacity (Icu): 36 kA at 415 V AC
• Rated voltage (Ue): 690 V AC 50/60 Hz per IEC 60947-2
• Utilisation category: Category A
