Anbieter: SCHNEIDER ELECTRIC
Schneider EPH0200169 Asfora 2-Pole Switch 10 AX 250 V AC Bronze
Beschreibung
The Schneider Electric EPH0200169 is a 2-pole switch from the Asfora wiring device range, finished in Bronze and supplied without a cover frame.
Technical specifications:
- Range: Asfora
- Product type: Switch
- Device presentation: Mechanism with fixing frame and cover plate
- Switch function: 2-pole 1-way
- Colour: Bronze
- Mounting: Flush
- Actuator: Rocker
- Rated current: 10 AX at 250 V AC
- Wire stripping length: 13.0 mm
- Material: ABS (acrylonitrile butadiene-styrene)
- Conductor material: Copper
- Terminals: Screwless terminals
- Width: 71 mm
- Height: 71 mm
- Depth: 43.0 mm
- Weight: 0.0611 kg
- Standards: IEC 60669-1
- IP rating: IP20
