Schneider GV4PE80N TeSys GV4 Motor Circuit Breaker 3P 80A 50kA

The Schneider Electric GV4PE80N is a 3-pole thermal magnetic motor circuit breaker in the TeSys GV4 range, rated at 80 A with a 50 kA Icu breaking capacity, designed for the protection and starting of AC motors in industrial installations.

• Reference: GV4PE80N
• Range: TeSys GV4
• Product type: Motor circuit breaker
• Poles: 3P
• Rated current (In): 80 A
• Breaking capacity (Icu): 50 kA
• Protection type: Thermal magnetic
• Motor power: 30 kW at 500 V AC 50/60 Hz; 37 kW at 400–415 V AC 50/60 Hz
• Utilisation category: AC-3 (IEC 60947-4-1)
• Terminals: Everlink
