Schneider GVAN20 TeSys Deca Auxiliary Contact Block 2NO Left Side Mount

The Schneider Electric GVAN20 is a 2 NO auxiliary contact block for the TeSys GV2 and GV3 series motor circuit breakers, designed for left-side mounting to provide status signaling and control circuit feedback. It supports a rated operational voltage of 48 to 690V AC and 24 to 240V DC, with a conventional thermal current of 6A in air.

Technical specifications:

• Commercial reference: GVAN20
• Manufacturer: Schneider Electric
• EAN: 3389110343502
• Series / range: TeSys / TeSys Deca
• Product type: Auxiliary contact block
• Contact arrangement: 2 NO
• Mounting location: Left side
• Compatible models: GV2ME, GV3P, GV2RT, GV2LE, GV2L, GV3L, GV2P
• Rated insulation voltage [Ui]: 690V (IEC 60947-1) / 600V (UL 508 / CSA C22.2 No 14)
• Rated operational voltage [Ue]: 48...690V AC / 24...240V DC
• Conventional thermal current [Ith]: 6A
• Minimum switching current: 5mA
• Minimum switching voltage: 17V
• Mechanical endurance: 100,000 cycles
• Electrical endurance: 100,000 cycles (AC-15 / DC-13)
• Tightening torque: 1.4 N.m (screw terminal blocks)
• Dimensions (W x H x D): 9.3 x 89 x 66mm
• Weight: 0.05 kg
• Color: Dark grey
• Certification: UKCA
• Warranty: 18 months

Features and benefits:

• Left-side mounting for direct attachment to TeSys GV2 and GV3 motor circuit breakers without additional wiring
• 2 NO contact arrangement for status indication and control interlocking
• Wide operational voltage range covering 48 to 690V AC and 24 to 240V DC
• High mechanical and electrical endurance rated at 100,000 cycles
• Low minimum switching current of 5mA, suitable for sensitive PLC and relay control circuits
• Broad model compatibility across the TeSys GV2 and GV3 product family

Applications:

• Signaling motor running or stopped status in motor control centers
• Remote position indication for GV2 and GV3 motor circuit breakers in control panels
• Interlocking circuits in industrial automation and switchgear assemblies
• Feedback signals to PLCs monitoring motor protection device state
• Motor protection status monitoring in industrial machinery and process equipment

Compliant with IEC 60947-1, UL 508, and CSA C22.2 No 14. Part of the Schneider Electric TeSys Deca range.

Also known as: Schneider GVAN20, Schneider Electric GVAN20, TeSys auxiliary contact block, GV2 auxiliary contact block.
