Schneider LC1D128P7 TeSys D Contactor 4P 2NO+2NC 25A AC-1 230V AC Coil

The Schneider Electric LC1D128P7 is a 4-pole contactor from the TeSys D range, designed for switching resistive and slightly inductive loads under utilisation category AC-1.

• Reference: LC1D128P7
• Range: TeSys D
• Model: LC1D
• Type: Contactor
• Poles: 4P
• Contact composition: 2 NO + 2 NC
• Rated operational current (Ie): 25 A at ≤440 V AC (AC-1, < 60 °C)
• Utilisation category: AC-1
• Rated voltage (Ue): ≤690 V AC, 25...400 Hz
• Coil voltage: 230 V AC
