Schneider LC1DT20P7 TeSys D Contactor 4P 4NO 20A 230V AC Coil

The Schneider Electric LC1DT20P7 is a 4-pole TeSys D series contactor rated for AC-1 utilisation, suitable for switching resistive and slightly inductive loads up to 20 A at 440 V AC. It features four normally open main poles and a 230 V AC 50/60 Hz control coil.

• Reference: LC1DT20P7
• Range: TeSys D
• Model: LC1D
• Type: Contactor
• Poles: 4P
• Contact configuration: 4 NO (4 normally open main poles)
• Rated current (Ie): 20 A at AC-1, ≤ 440 V AC (< 60 °C)
• Utilisation category: AC-1
• Rated voltage (Ue): ≤ 690 V AC, 25...400 Hz
• Coil voltage: 230 V AC, 50/60 Hz
