Schneider LC1G225LSEA TeSys Giga Contactor 3P 3NO 225A 55kW 200-500V AC/DC Coil

The Schneider Electric LC1G225LSEA is a 3-pole high-power contactor from the TeSys Giga range, rated at 225 A under AC-3 duty and suited to power switching and three-phase motor control at up to 440 V AC.

• Reference: LC1G225LSEA
• Range: TeSys Giga
• Model: LC1G
• Poles: 3P
• Contact configuration: 3NO
• Rated current Ie (AC-3): 225 A at ≤440 V AC
• Utilisation category: Power switching
• Motor power (AC-3e): 55 kW at 230 V AC, 50/60 Hz
• Coil voltage: 200–500 V AC/DC (wide-range coil)
