Schneider LC1K0601P7 TeSys K Contactor 3P 3NO 6A 1.5kW 230V AC Coil

The LC1K0601P7 is a 3-pole AC contactor from Schneider Electric's TeSys K range, designed for AC-3 motor switching and general load control duties.

• Reference: LC1K0601P7
• Range: TeSys K
• Type: Contactor
• Number of poles: 3P
• Contact composition: 3 NO (normally open)
• Rated operational current (Ie): 6 A at < = 440 V AC, AC-3, at < 60 °C
• Utilisation category: AC-3
• Motor power (AC-3): 1.5 kW at 220–230 V AC, 50/60 Hz
• Rated voltage (Ue): < = 690 V AC, < = 400 Hz (power circuit)
• Coil voltage: 230 V AC
