Schneider LC1K0901P7 TeSys K Contactor 3P 9A 2.2kW 230V AC Coil

The Schneider Electric LC1K0901P7 is a 3-pole contactor from the TeSys K range, designed for motor switching and control applications under utilisation category AC-3.

• Reference: LC1K0901P7
• Range: TeSys K
• Poles: 3P
• Contact configuration: 3 NO
• Rated current Ie (AC-3): 9 A at ≤440 V AC
• Utilisation category: AC-3
• Coil voltage: 230 V AC
• Motor power (AC-3): 2.2 kW at 220–230 V AC, 50/60 Hz
• Rated voltage Ue (main circuit): ≤690 V AC, ≤400 Hz
