Schneider LC1K0910B7 TeSys K Contactor 3P 3NO 9A 2.2kW 24V AC Coil

The Schneider Electric LC1K0910B7 is a TeSys K series 3-pole contactor designed for switching AC motor loads and resistive circuits in industrial control applications.

• Reference: LC1K0910B7
• Range: TeSys K
• Poles: 3P
• Contact configuration: 3 NO (normally open)
• Rated operational current Ie: 9 A at ≤440 V AC (AC-3, < 60 °C)
• Utilisation category: AC-3
• Motor power (AC-3): 2.2 kW at 220–230 V AC 50/60 Hz
• Rated voltage Ue: ≤690 V AC, ≤400 Hz
• Coil voltage: 24 V AC
