Schneider LC1K0910P7 TeSys K Contactor 3P 3NO 9A 2.2kW 230V AC Coil

The Schneider Electric LC1K0910P7 is a 3-pole TeSys K contactor designed for motor switching in AC-3 applications. It features a 230 V AC coil and a main circuit rated at 9 A at ≤440 V, suitable for controlling motors up to 2.2 kW at 220–230 V AC.

• Reference: LC1K0910P7
• Range: TeSys K
• Type: Contactor
• Poles: 3P
• Contact configuration: 3 NO
• Rated current Ie (AC-3, ≤440 V AC): 9 A
• Utilisation category: AC-3
• Coil voltage: 230 V AC
• Motor power (AC-3, 220–230 V AC, 50/60 Hz): 2.2 kW
