Schneider LC1K1210P7 TeSys K Contactor 3P 3NO 12A 3kW 230V AC Coil

The Schneider Electric LC1K1210P7 is a TeSys K series 3-pole AC-3 contactor for motor control and switching. The main circuit is rated up to 690 V AC (≤400 Hz), actuated by a 230 V AC coil.

• Reference: LC1K1210P7
• Range: TeSys K
• Type: Contactor
• Poles: 3P
• Contact configuration: 3 NO
• Rated operational current (Ie): 12 A at ≤440 V AC, AC-3 (< 60 °C)
• Utilisation category: AC-3
• Motor power (AC-3): 3 kW at 220–230 V AC, 50/60 Hz
• Coil voltage: 230 V AC
