Schneider LC1K1610B7 TeSys K Contactor 3P 3NO 16A 4kW 24V AC Coil

The LC1K1610B7 is a 3-pole contactor from Schneider Electric's TeSys K range, designed for switching AC motor loads and resistive circuits at up to 16 A in AC-3 utilisation category.

• Reference: LC1K1610B7
• Range / Model: TeSys K, LC1K
• Type: Contactor
• Poles / Contact configuration: 3P, 3 NO
• Rated operational current (Ie): 16 A at ≤440 V AC (AC-3, < 60 °C)
• Rated voltage (Ue): ≤690 V AC, ≤400 Hz (main circuit)
• Utilisation category: AC-3
• Motor power (AC-3): 4 kW at 220...230 V AC, 50/60 Hz
• Coil voltage: 24 V AC
