Schneider LC1K1610P7 TeSys K Contactor 3P 3NO 16A 4kW 230V AC Coil

The LC1K1610P7 is a 3-pole contactor from Schneider Electric's TeSys K range, designed for switching AC induction motor loads under IEC utilisation category AC-3.

• Reference: LC1K1610P7
• Range: TeSys K
• Type: Contactor
• Poles: 3P
• Contact configuration: 3 NO (main circuit)
• Rated current Ie (AC-3): 16 A at ≤ 440 V AC (< 60 ° C)
• Utilisation category: AC-3
• Coil voltage: 230 V AC
• Motor power (AC-3): 4 kW at 220– 230 V AC, 50/60 Hz
