Schneider LC2D09P7 TeSys D Reversing Contactor 3P 9A 2.2kW 230V AC

The Schneider Electric LC2D09P7 is a TeSys D reversing contactor for electromechanical control of three-phase AC motor direction in industrial installations. It belongs to the TeSys D product range and is suited to AC motor reversing duties.

• Reference: LC2D09P7
• Product line: TeSys D
• Type: Reversing contactor
• Poles: 3P (3 NO)
• Rated operational current (Ie): 9 A at ≤440 V AC (AC-3)
• Rated voltage (Ue): ≤690 V AC, 25–400 Hz
• Motor power (AC-3): 2.2 kW at 220–230 V AC, 50/60 Hz
• Coil voltage: 230 V AC
• Utilisation category: AC-1
