Schneider LC2K0910P7 TeSys K Reversing Contactor 3P 9A 2.2kW 230V AC Coil

The Schneider Electric LC2K0910P7 is a TeSys K reversing contactor designed for three-phase AC motor control in forward/reverse duty. It operates within utilisation category AC-3 and provides directional motor switching in a single assembly.

• Reference: LC2K0910P7
• Range: TeSys K
• Type: Reversing contactor
• Main poles: 3P (3 NO)
• Rated operational current (Ie): 9 A (AC-3, ≤440 V, <60 °C)
• Utilisation category: AC-3
• Rated voltage (Ue): 690 V AC 50/60 Hz
• Motor power: 2.2 kW at 220–230 V AC 50/60 Hz
• Coil voltage: 230 V AC
