Schneider LC2K1210P7 TeSys K Reversing Contactor 3P 12A 3kW 230V AC Coil

The Schneider Electric LC2K1210P7 is a TeSys K reversing contactor for three-phase AC motor applications requiring direction reversal, rated to AC-3 duty with a 230 V AC coil.

• Reference: LC2K1210P7
• Range: TeSys K
• Type: Reversing contactor
• Poles: 3P
• Contact composition (main circuit): 3 NO
• Rated operational current (Ie): 12 A at ≤440 V AC, AC-3 (< 60 °C)
• Utilisation category: AC-3
• Motor power (AC-3): 3 kW at 220–230 V AC 50/60 Hz
• Coil voltage: 230 V AC
