Schneider LV431411 ComPact NSX250N MCCB Basic Frame 250 A 50 kA 4P

The Schneider Electric LV431411 is a 4-pole moulded-case circuit breaker (MCCB) basic frame from the ComPact NSX range, rated at 250 A with a breaking capacity of 50 kA at 415 VAC 50/60 Hz. Supplied without a trip unit, it is designed to be completed with a separately ordered trip unit to configure protection to specific installation requirements.

• Reference: LV431411
• Range: ComPact NSX
• Model: NSX250N
• Type: Moulded-case circuit breaker (MCCB) basic frame
• Poles: 4
• Rated current: 250 A
• Breaking capacity: 50 kA at 415 VAC
• Frequency: 50/60 Hz
• Trip unit: None (supplied without trip unit)
