WAGO 222-415 Splicing Connector with Levers 5-Pole 4 mm² 32 - Pack of 40

The WAGO 222-415 is a 5-conductor splicing connector with levers from the 222 Series, designed for all conductor types using CAGE CLAMP® connection technology. Rated at 400 V and 32 A, it accepts conductor cross-sections from 0.08 mm² to 4 mm² (fine-stranded) with side-entry wiring and a strip length of 9 ... 10 mm.

Technical specifications:

• Catalog number: 222-415
• Manufacturer: WAGO
• Series: 222
• Type: Splicing connector with levers, CAGE CLAMP®
• Clamping units: 5
• Rated voltage: 400 V (overvoltage category II, pollution degree 2)
• Rated impulse withstand voltage: 4 kV
• Rated current: 32 A
• Conductor materials: Copper, Aluminum
• Solid conductor: 0.08 ... 2.5 mm² / 28 ... 12 AWG
• Stranded conductor: 0.08 ... 2.5 mm² / 28 ... 12 AWG
• Fine-stranded conductor: 0.08 ... 4 mm² / 28 ... 12 AWG
• Strip length: 9 ... 10 mm / 0.35 ... 0.39 in
• Wiring direction: Side-entry
• Dimensions (W × H × D): 26.6 × 14.5 × 20.5 mm
• Weight: 6.6 g
• Housing color: gray; actuator color: orange
• Flammability class: UL94 V0
• Ambient temperature (operation): max. +40 °C
• Continuous operating temperature: 85 °C
• GTIN: 4044918464956
• Country of origin: Germany (DE)
• RoHS: Compliant, no exemption
• Certifications: ENEC 15 (EN 60998), UL 486C (E69654), UL 467 (E201573), EU Declaration of Conformity, UK Declaration of Conformity; marine approvals: ABS, LR (EN 60998), PRS (EN 60998)

Features and benefits:

• Tool-free lever actuation - lift lever to open clamping unit, lower to close - for fast conductor termination without additional tools
• Transparent housing allows immediate visual inspection of correct conductor contact for solid, stranded, and fine-stranded conductors
• Accepts copper and aluminum conductors in solid, stranded, and fine-stranded form in a single connector
• Compact dimensions (26.6 × 14.5 × 20.5 mm) for efficient installation in junction boxes and enclosures
• UL94 V0 housing; approved to ENEC 15, UL 486C, and UL 467 with additional marine certifications from ABS, LR, and PRS

Applications:

• Intercom system wiring
• Connecting electrical ovens
• Splicing solid, stranded, or fine-stranded conductors in junction boxes
• High-load circuits requiring connections up to 32 A / 400 V

Also known as: WAGO 222-415, WAGO 5-conductor lever splicing connector, CAGE CLAMP splicing connector 5-pole.
