Weidmuller 3052290000 CRI10024 Relay 1CO 24V DC 16A

The Weidmüller CRI10024 (order no. 3052290000) is a plug-in relay from the CUBESERIES range, fitted with a 24 V DC coil and a single changeover contact. It connects via a plug-in terminal with a 5.00 mm pitch and is supplied without a test button, identified by a blue plug.

• Contact configuration: 1 CO (changeover) contact, silver-nickel (AgNi)
• Rated control voltage: 24 V DC
• Coil data: Power rating 400 mW; coil resistance 1440 Ω ± 10%; rated DC coil current 16.7 mA
• Continuous current: 16 A
• Max. switching voltage: 250 V AC / 250 V DC
• Switching capacity (resistive): 4000 VA AC max.; 384 W DC @ 24 V
• Inrush current: 24 A / 20 ms
• Switching delays: Switch-on ≤ 12 ms; switch-off ≤ 6 ms
• Mechanical service life: 3 × 107 switching cycles
• Operating temperature: −20 °C to +70 °C; storage −40 °C to +85 °C
• Protection & insulation: IP40; impulse withstand voltage 4 kV (1.2/50 µs); dielectric strength (control–load side) 5 kVeff / 1 min; pollution severity class 3
• Dimensions (W × H × D): 12.7 mm × 29 mm × 15.7 mm; net weight 14 g
• Connection: Plug-in; pitch 5.00 mm
• Approvals & compliance: RoHS compliant (no exemption); REACH: no SVHC above 0.1 wt%; cURus certificate E223474; CSA certificate 607178-80219312; UL 94 flammability rating V-2
