Weidmuller 8869800000 RCI314012 Relay 1CO 12V DC 16A

The Weidmuller 8869800000 RCI314012 is a pluggable DIN rail relay with 1CO contacts, 12V DC coil voltage, and 16A contact current rating. Designed for use with a compatible Weidmuller relay socket for tool-free relay replacement without disturbing field wiring.

Technical specifications:

• Part number: 8869800000
• Model: RCI314012
• Contact configuration: 1CO
• Coil voltage: 12V DC
• Contact current: 16A
• Contact voltage: up to 250V AC
• Mounting: Pluggable into relay socket (DIN rail)
• Standard: IEC 61810-1

Applications:

• Switching control signals in PLC output and relay circuits
• Voltage and current isolation between control and field circuits
• Industrial automation relay outputs in machine panels

Also known as: Weidmuller 8869800000, RCI314012, RCI relay 12V DC 1CO, Weidmuller 1CO relay 12V DC.
