Weidmuller 8869870000 RCI424012 Relay 2CO 12V DC 8A

The Weidmuller 8869870000 RCI424012 is a pluggable DIN rail relay with 2CO contacts, 12V DC coil voltage, and 8A contact current rating. Designed for use with a compatible Weidmuller relay socket for tool-free relay replacement without disturbing field wiring.

Technical specifications:

• Part number: 8869870000
• Model: RCI424012
• Contact configuration: 2CO
• Coil voltage: 12V DC
• Contact current: 8A
• Contact voltage: up to 250V AC
• Mounting: Pluggable into relay socket (DIN rail)
• Standard: IEC 61810-1

Applications:

• Switching control signals in PLC output and relay circuits
• Voltage and current isolation between control and field circuits
• Industrial automation relay outputs in machine panels

Also known as: Weidmuller 8869870000, RCI424012, RCI relay 12V DC 2CO, Weidmuller 2CO relay 12V DC.
