XCKM115 Telemecanique Limit Switch Thermoplastic Roller Lever 1NC+1NO Pg11

The Telemecanique XCKM115 is a thermoplastic limit switch from the XCKM series, fitted with a roller lever actuator and Pg11 cable entry. It provides 1 normally closed and 1 normally open contact (1NC+1NO) with snap action and is rated for 240V AC 3A. The XCKM series uses a compact thermoplastic enclosure with IP66/67 ingress protection.

• Series: XCKM
• Actuator: thermoplastic roller lever
• Contacts: 1NC+1NO
• Action: snap
• Cable entry: Pg11
• Rated voltage: 240V AC
• Rated current: 3A
• Enclosure: thermoplastic, IP66/67
• Standards: IEC 60947-5-1

The XCKM115 is suitable for position detection, end-of-travel detection, and machine guarding applications in industrial machinery and conveyor systems. The Pg11 cable gland accepts cables up to approximately 10mm outer diameter. Catalog number: XCKM115.
